Model Configurations
Processor Intel® Core Ultra 7 255H, 16C (6P + 8E + 2LPE) / 16T, Max Turbo up to 5.1GHz, 24MB Intel Smart Cache
AI PC Category AI PC
NPU Integrated Intel® AI Boost, up to 13 TOPS
Graphics Integrated Intel® Arc™ 140T GPU Functions as Intel Graphics
Chipset Intel® SoC Platform
Memory 1x 16GB SODIMM DDR5-5600
Memory Slots Raptor Lake, Meteor Lake and Arrow Lake: two DDR5 SODIMM slots, dual-channel capable
Max Memory Raptor Lake with H Series processors, Meteor Lake and Arrow Lake: up to 64GB DDR5-5600
Storage 512GB SSD M.2 2242 PCIe® 4.0x4 NVMe® Opal 2.0
Storage Slot Raptor Lake, Meteor Lake and Arrow Lake: two M.2 slots • One M.2 2242 PCIe® 4.0 x4 slot • One M.2 2280 PCIe 4.0 x4 slot
Max Storage Support Raptor Lake, Meteor Lake and Arrow Lake: up to two drives, 2x M.2 SSD • M.2 2242 SSD up to 1TB • M.2 2280 SSD up to 1TB
Card Reader No card reader
Audio Chip High Definition (HD) Audio, Senary SN6147 codec
Speakers Stereo speakers, 2W x2, Dolby Atmos®, audio by HARMAN
Microphone 2x, Array
Camera FHD 1080p + IR Hybrid with Privacy Shutter
Battery 48Wh
Power Adapter 65W USB-C® (3-pin)
Display 16" WUXGA (1920x1200) IPS 300nits Anti-glare, 45% NTSC, 60Hz
Touchscreen None
Screen-to-Body Ratio 90.7%
Pen Pen Not Supported
Keyboard Backlit, English (EU)
Dimensions (WxDxH) 356 x 249 x 10.1/17.05 (front/rear), 21.15 (maximum) mm; 14.01 x 9.80 x 0.40/0.67 (front/rear), 0.83 (maximum) inches
Weight Starting at 1.63 kg (3.59 lbs)
Case Color Black
Case Material Aluminium (Top), Aluminium (Bottom)
CONNECTIVITY
WLAN + Bluetooth Intel® Wi-Fi® 6E AX211, 802.11ax 2x2 + BT5.3
WWAN WWAN Not Supported
SIM Card None
Ethernet 100/1000M (RJ-45)
NFC None
Standard Ports
1x USB-A (USB 5Gbps / USB 3.2 Gen 1)
1x USB-A (USB 10Gbps / USB 3.2 Gen 2), Always On
1x USB-C® (USB 20Gbps / USB 3.2 Gen 2x2), with USB PD 3.1 and DisplayPort™ 1.4
1x USB-C® (Thunderbolt™ 4 / USB4® 40Gbps), with USB PD 3.1 and DisplayPort™ 2.1
1x HDMI® 2.1, up to 4K/60Hz
1x Headphone / microphone combo jack (3.5mm)
1x Ethernet (RJ-45)
SECURITY & PRIVACY
ThinkShield ThinkShield is a comprehensive security solution that encompasses hardware, software, and supply chain components. For more detials, visit here
Security Chip Discrete TPM 2.0 Enabled
Physical Locks Kensington® Nano Security Slot, 2.5 x 6 mm
Smart Card Reader None
Fingerprint Reader Touch Style, Match-on-Chip, Integrated in Power Button
Other Security
Camera privacy shutter
IR camera for Windows® Hello (facial recognition)
ACCESSORIES
Bundled Accessories Lenovo® 15.6" Laptop Casual Toploader
CERTIFICATIONS
Green Certifications
ErP Lot 6/26
RoHS compliant
TCO Certified, generation 10
Mil-Spec Test MIL-STD-810H military test passed
Other Certifications TÜV Rheinland® Low Blue Light (Software Solution)
Model 21SR005NGQ
